CI Tech Tip: Cambo WRS Macro Adapters
When using a Rodenstock 90mm f/5.6 HR Digaron-SW lens, or a Schneider 120mm f/5.6 Asph. N Apo-Digitar lens, you will need to have macro adapters for use beyond the minimum focusing distance of the lens. We’ve compiled a list of what focusing distance you can expect with each spacer below:
Performance with Schneider 120mm f/5.6 Asph. N Apo-Digitar
| Spacer | Focus Range (centimeters) | Focus Range (Inches) |
|---|---|---|
| 10mm | 100cm-150cm | 39.3"-59" |
| 17mm | 70cm-100cm | 27.5"-39.3" |
| 27mm (10mm + 17MM together) | 56cm-65cm | 22"-25.5" |
| 48mm | 39cm-42cm | 15.3"-16.5" |
Performance with Rodenstock 90mm f/5.6 HR Digaron-SW
| Spacer | Focus Range (centimeters) | Focus Range (Inches) |
|---|---|---|
| 10mm | 60cm-90cm | 23.6"-35.4" |
| 17mm | 44cm-60cm | 17.3"-23.6" |
| 27mm (10mm + 17MM together) | 28cm-39cm | 11"-15.3" |
| 48mm | 24cm-26cm | 9.4"-10.2" |
All products listed above are available from Capture Integration. Contact us to learn more about these products, as well as many more tools not listed here. The Capture Integration sales team can help you with any/all of your photography needs.
